Calculation examples
We provide the calculation examples as input files for IngSoft EasyPipe. Their file extension is .epn. To download these files to your computer, please click the desired file with the right mouse button and select Save target/link as.... Then specify the destination directory on your hard disk.
- Calculationexamples IngSoft EasyPipe DWA-A 127-10 Material properties
Input file with variants (Professional Edition) for thermoplastics
EPN, approx. 1.3 MB, 2023-05 - Calculationexamples IngSoft EasyPipe ATV-DVWK-A 127 Trench
EPN, approx. 330 kB, 2023-05 - Calculation examples IngSoftEasyPipe DWA-A 161 jacking
EPN, approx. 860 kB, 2023-05 - Calculation examples IngSoftEasyPipe DWA-A 143-2 Liner
EPN, approx. 83 kB, 2023-05 - Calculation examples IngSoft EasyPipe SIA 190:2017 + D 0263 Trench
EPN, approx. 330 kB, 2023-05
For the execution of a project, structural engineers need to know the specific boundary conditions: Cover height, soil properties, pipe geometry, material, information on traffic loads and groundwater. Depending on the process, further information is required.
The regulations contain suggestions which we provide here as forms. You can fill them out directly on your screen.
To download these files to your computer, please click on the desired file with the right mouse button and select Save target/link as.... Then specify the target directory on your hard disk.
Minimum details
Object questionnaires from the DWA rules and regulations
Form (extract from ATV-DVWK-A 127:2000) asks for typical information for open new installations: Cover height, geometry, material characteristics, loads, soil characteristics, information on installation, shoring
The form asks for information typical for rehabilitation: Old pipe, old pipe condition (AZ I-III), rehabilitation method, geometry, material characteristics, loads, soil characteristics and other effects.
Form (extract from DWA-A 161:20214) asks for typical information for pipe jacking: Tunnelling method, curve radius, geometry, material parameters, loads, soil parameters, information on the Pressure Transfer Ring (PTR)
